The RB530 antibody recognizes microtubules by immunofluorescence


  • Eloïse Bertiaux-Lequoy
  • Philippe Hammel
  • Virginie Hamel
  • Paul Guichard



The RB530 antibody detects microtubules by immunofluorescence in the green algae Chlamydomonas reinhardtii and in human cells in culture.


Microtubules are polymers of α- and ß-tubulin essential for many biological fundamental processes ranging from cytoskeleton organization to cell division (Janke andBulinski, 2011). Here, we describe the ability of the RB530 antibody to recognize microtubules by immunofluorescence.

Materials & Methods

Antibodies: ABCD_RB530 antibody (ABCD nomenclature, was produced by the Geneva Antibody Facility (Blanc et al., 2014; as a mini-antibody with the antigen-binding scFv fused to a mouse IgG2A Fc (MRB530). HEK293 suspension cells (growing in FreeStyleTM 293 Expression Medium, Gibco #12338) were transiently transfected with the vector coding for the scFv-Fc. Supernatant (100 mg/L) was collected after 4 days.

Antigen: The antibodies were originally raised against microtubules polymerized in vitro. Microtubules were polymerized in the presence of pure tubulin (Cytoskeleton Inc. #T240) with 5% of tubulin biotin (Cytoskeleton Inc. #T333P). To do so, the tubulin mix (10 µl at 5 mg/ml) was dialyzed in MES buffer pH 6.9 (MES 10mM, MgCl2 1mM, EGTA 1mM) during 1 hour at 4 °C. To produce microtubules without C-terminal tails (Schmidt-Cernohorska et al., 2019), tubulin was incubated at 25 °C during 45 min in the presence of subtilisin (0.2 µl at 1 mg/ml). The reaction was stopped using 0.1 µl PMSF (10 mM). Microtubules were then polymerized using taxol (final concentration 60 µM) for 40 min at 37 °C.

Protocol: U2OS cells were grown on 12 mm coverslips at 37 °C with 5% CO2 in DMEM supplemented with GlutaMAX (Life Technology), 10% tetracycline-negative fetal calf serum (Brunschwig), penicillin and streptomycin (100 µg/ml). Chlamydomonas reinhardtii cells were grown in liquid Tris-acetate-phosphate medium (TAP medium containing TRACE; Hutner et al., 1950) at 22 °C. Before fixation, Chlamydomonas reinhardtii cells were sedimented 30 min on 12 mm coverslips in a humid chamber. Cells on coverslips were fixed in cold methanol (-20 °C) for 7 min and blocked with PBS + 2% (w/v) BSA (PBS-BSA) for 15 min. Cells were then incubated for 1 hour with MRB530 diluted in PBS-BSA (1:250) and rabbit anti-beta tubulin (1:500, Abcam #Ab18251). Next, the coverslips were washed three times for 10 min in PBS-Tween 0.1% and incubated for 1 hour with secondary antibodies goat anti-mouse coupled to Alexa 488 (1:500, Invitrogen #A11029) and goat anti-rabbit coupled to Alexa 568 (1:500, Invitrogen #A11036). After 3 washes (10 min) with PBS-Tween 0.1%, coverslips were mounted in glycerol mounting medium containing DAPI (Abcam). Imaging was done on a Zeiss LSM780 microscope, using a 63x oil immersion objective.


The MRB530 antibody labels both the axoneme of Chlamydomonas reinhardtii flagella as well as the basal body at its base (Fig. 1, inset). MRB530 also recognizes microtubules of the cytoskeleton of both Chlamydomonas reinhardtii and U2OS cells (Figs. 1 and 2).

Figure 1. MRB530 antibody labels microtubules, the flagellum and the basal body in C. reinhardtii cells. Representative confocal image of a Chlamydomonas cell co-stained with the antibody MRB530 (green) and anti-beta tubulin Ab18251 (magenta). The inset shows the basal body. Scale bar: 5 µm.

Figure 2. MRB530 antibody recognizes microtubules in human U2OS cells. Representative confocal image of U2OS cells co-stained with MRB530 (green), anti-beta tubulin Ab18251 (magenta) and DAPI (blue). Note the colocalization between the control anti-tubulin Ab18251 antibody and MRB530. Scale bar: 5 µm.

Conflict of interest

The authors declare no conflict of interest.


Blanc C, Zufferey M, Cosson P. Use of in vivo biotinylated GST fusion proteins to select recombinant antibodies. ALTEX. 2014; 31(1):37-42. PMID:24100547

Janke C, Bulinski JC. Post-translational regulation of the microtubule cytoskeleton: mechanisms and functions. Nat Rev Mol Cell Biol. 2011; 12(12):773-86. PMID:22086369

Hutner SH, Provasoli L, Schatz A, Haskins CP. Some approaches to the study of the role of metals in the metabolism of microorganisms. Proc. Am. Philos. Soc. 1950; 94(2):152-170.

Schmidt-Cernohorska M, Zhernov I, Steib E, et al. Flagellar microtubule doublet assembly in vitro reveals a regulatory role of tubulin C-terminal tails. Science. 2019; 363(6424):285-288. PMID:30655442






How to Cite

Bertiaux-Lequoy E, Hammel P, Hamel V, Guichard P. The RB530 antibody recognizes microtubules by immunofluorescence. Antib. Rep. [Internet]. 2019 Sep. 21 [cited 2024 Jun. 17];2(4):e65. Available from:
